Electronic Tricks Lora/LoraWan shield for Raspberry Pi Zero and PI3

For the example code so far I had been using the Dragino LoRa GPS HAT for Raspberry PI which, after looking at the schematic (to figure out how the chip select line was connected) worked pretty well.

I had also purchased a Lora/LoRaWAN shield for Raspberry PI Zero and PI3 from Tindie (plus some unpopulated printed circuit boards so I can try building a RFM69HCW based shield).

The board didn’t fit on my Raspberry PI 2 & 3 devices so I used a Dexter industries Grove PI0 Shield as a temporary spacer to lift the antenna connector above the USB sockets.

The RFM95 chip select line is connected to pin 24 (GPIO8), the reset line to pin 29(GPIO5) and the interrupt line (RFM95 DIO0) to pin 22(GPIO25).

ElectronicTricksRFM95

My board doesn’t have any Light Emitting Diodes (LEDs) so it was straight into reading register values

//---------------------------------------------------------------------------------
// Copyright (c) July 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ElectronicTricksSPI
{
	using System;
	using System.Diagnostics;
	using System.Threading;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Spi;

	public sealed class StartupTask : IBackgroundTask
	{
		public void Run(IBackgroundTaskInstance taskInstance)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(0) // GPIO8 Electronic Tricks
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,   // From SemTech docs pg 80 CPOL=0, CPHA=0
			};

			SpiDevice Device = spiController.GetDevice(settings);

			while (true)
			{
				byte[] writeBuffer = new byte[] { 0x42 }; // RegVersion
				byte[] readBuffer = new byte[1];

				Device.TransferSequential(writeBuffer, readBuffer);

				byte registerValue = readBuffer[0];
				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", 0x42, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));

				Thread.Sleep(10000);
			}
		}
	}
}

The debug output confirmed I was reading the right value from the RegVer register

Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010

The antenna connector not clearing the USB socket is an issue which I’ll solve with a socket like the one on the GrovePI which has longer leads and acts as a spacer.
ElectronicTricksLoraShield

Elecrow Lora RFM95 IOT Board for RPI

For the example code so far I had been using the Dragino LoRa GPS HAT for Raspberry PI which after looking at the schematic (to figure out how the chip select line was connected) worked pretty well.

I had also purchased a Lora RFM95 IOT Board for RPI from Elecrow and was keen to get that working for applications which don’t require Global Positioning System (GPS) support.

The RFM95 chip select line is connected to pin 26 (GPIO7), the reset line to pin 15(GPIO22) and the interrupt line (RFM96 DIO0) to pin 22(GPIO25).

Lora RFM95 IOT Board for RPI V1.0

The shield had a Light Emitting Diode (LED) connected to General Purpose Input Output (GPIO) 23 so the first step was to get that to flash.

//---------------------------------------------------------------------------------
// Copyright (c) July 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ElecrowLed
{
	using System;
	using System.Threading;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Gpio;

	public sealed class StartupTask : IBackgroundTask
	{
		public void Run(IBackgroundTaskInstance taskInstance)
		{
			GpioController gpioController = GpioController.GetDefault();
			GpioPin yellowLedPin = gpioController.OpenPin(23);
			yellowLedPin.SetDriveMode(GpioPinDriveMode.Output);

			while (true)
			{
				if (yellowLedPin.Read() == GpioPinValue.High)
				{
					yellowLedPin.Write(GpioPinValue.Low);
				}
				else
				{
					yellowLedPin.Write(GpioPinValue.High);
				}
				Thread.Sleep(500);
			}
		}
	}
}

To confirm I could access the RMF95 registers over the Serial Peripheral Interface (SPI) I read the RegVersion register.

//---------------------------------------------------------------------------------
// Copyright (c) July 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ElecrowSPI
{
	using System;
	using System.Diagnostics;
	using System.Threading;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Spi;

	public sealed class StartupTask : IBackgroundTask
    {
		public void Run(IBackgroundTaskInstance taskInstance)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(1)	// GPIO7 Elecrow shield
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,	// From SemTech docs pg 80 CPOL=0, CPHA=0
			};

			SpiDevice Device = spiController.GetDevice(settings);

			while (true)
			{
				byte[] writeBuffer = new byte[] { 0x42 }; // RegVersion
				byte[] readBuffer = new byte[1];

				Device.TransferSequential(writeBuffer, readBuffer);

				byte registerValue = readBuffer[0];
				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", 0x42, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));

				Thread.Sleep(10000);
			}
		}
	}
}

The debug output confirmed I was reading the right value from the RegVer register

Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010
Register 0x42 - Value 0X12 - Bits 00010010

I’m going to unsolder the coil antenna and replace it with a short SMA Extension drop cable so I can connect an external antenna.

ElecrowLoRaShield



RFM95/96/97/98 shield library Part9

RegisterManager Extraction Refactor

The code was getting really repetitive and nasty so figured it was time to extract the register manager class into a separate module. In an abandoned refactor I tried introducing an enumeration for the RFM9X Register addresses and extract the RegisterManager in one go but that caused too much churn.

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.RefactorRegisterManager
{
	using System;
	using System.Diagnostics;
	using System.Text;
	using System.Threading.Tasks;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Gpio;

	sealed class Rfm9XDevice
	{
		private GpioPin InterruptGpioPin = null;
		public RegisterManager RegisterManager = null; // Future refactor this will be made private

		public Rfm9XDevice(byte chipSelectPin, byte resetPin, byte interruptPin)
		{
			RegisterManager = new RegisterManager(chipSelectPin);

			// Setup the reset and interrupt pins
			GpioController gpioController = GpioController.GetDefault();

			// Reset pin configuration then strobe briefly to factory reset
			GpioPin resetGpioPin = gpioController.OpenPin(resetPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			resetGpioPin.Write(GpioPinValue.Low);
			Task.Delay(10);
			resetGpioPin.Write(GpioPinValue.High);
			Task.Delay(10);

			// Interrupt pin for RX message, TX done etc. notifications
			InterruptGpioPin = gpioController.OpenPin(interruptPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Input);

			InterruptGpioPin.ValueChanged += InterruptGpioPin_ValueChanged;
		}

		public void RegisterDump()
		{
			RegisterManager.Dump(0x0, 0x40);
		}

		private void InterruptGpioPin_ValueChanged(GpioPin sender, GpioPinValueChangedEventArgs args)
		{
			if (args.Edge != GpioPinEdge.RisingEdge)
			{
				return;
			}

			byte IrqFlags = this.RegisterManager.ReadByte(0x12); // RegIrqFlags
			Debug.WriteLine(string.Format("RegIrqFlags {0}", Convert.ToString(IrqFlags, 2).PadLeft(8, '0')));

			if ((IrqFlags & 0b01000000) == 0b01000000)  // RxDone
			{
				Debug.WriteLine("Receive-Message");
				byte currentFifoAddress = this.RegisterManager.ReadByte(0x10); // RegFifiRxCurrent
				this.RegisterManager.WriteByte(0x0d, currentFifoAddress); // RegFifoAddrPtr

				byte numberOfBytes = this.RegisterManager.ReadByte(0x13); // RegRxNbBytes

				// Allocate buffer for message
				byte[] messageBytes = new byte[numberOfBytes];

				for (int i = 0; i < numberOfBytes; i++)
				{
					messageBytes[i] = this.RegisterManager.ReadByte(0x00); // RegFifo
				}

				string messageText = UTF8Encoding.UTF8.GetString(messageBytes);
				Debug.WriteLine("Received {0} byte message {1}", messageBytes.Length, messageText);
			}

			if ((IrqFlags & 0b00001000) == 0b00001000)  // TxDone
			{
				this.RegisterManager.WriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous
				Debug.WriteLine("Transmit-Done");
			}

			this.RegisterManager.WriteByte(0x12, 0xff);// RegIrqFlags
		}
	}

	public sealed class StartupTask : IBackgroundTask
	{
		private const byte ChipSelectLine = 25;
		private const byte ResetLine = 17;
		private const byte InterruptLine = 4;
		private Rfm9XDevice rfm9XDevice = new Rfm9XDevice(ChipSelectLine, ResetLine, InterruptLine);
		private byte NessageCount = Byte.MaxValue;

		public void Run(IBackgroundTaskInstance taskInstance)
		{
			// Put device into LoRa + Sleep mode
			rfm9XDevice.RegisterManager.WriteByte(0x01, 0b10000000); // RegOpMode

			// Set the frequency to 915MHz
			byte[] frequencyWriteBytes = { 0xE4, 0xC0, 0x00 }; // RegFrMsb, RegFrMid, RegFrLsb
			rfm9XDevice.RegisterManager.Write(0x06, frequencyWriteBytes);

			rfm9XDevice.RegisterManager.WriteByte(0x0F, 0x0); // RegFifoRxBaseAddress

			// More power PA Boost
			rfm9XDevice.RegisterManager.WriteByte(0x09, 0b10000000); // RegPaConfig

			rfm9XDevice.RegisterManager.WriteByte(0x40, 0b01000000); // RegDioMapping1 0b00000000 DI0 RxReady & TxReady

			rfm9XDevice.RegisterManager.WriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous

			rfm9XDevice.RegisterDump();

			while (true)
			{
				rfm9XDevice.RegisterManager.WriteByte(0x0E, 0x0); // RegFifoTxBaseAddress

				// Set the Register Fifo address pointer
				rfm9XDevice.RegisterManager.WriteByte(0x0D, 0x0); // RegFifoAddrPtr

				string messageText = "W10 IoT Core LoRa! " + NessageCount.ToString();
				NessageCount -= 1;

				// load the message into the fifo
				byte[] messageBytes = UTF8Encoding.UTF8.GetBytes(messageText);
				foreach (byte b in messageBytes)
				{
					rfm9XDevice.RegisterManager.WriteByte(0x0, b); // RegFifo
				}

				// Set the length of the message in the fifo
				rfm9XDevice.RegisterManager.WriteByte(0x22, (byte)messageBytes.Length); // RegPayloadLength
				rfm9XDevice.RegisterManager.WriteByte(0x01, 0b10000011); // RegOpMode

				Debug.WriteLine("Sending {0} bytes message {1}", messageBytes.Length, messageText);

				Task.Delay(10000).Wait();
			}
		}
	}
}

I also started some basic modifications to the register manager class to make it reusable for other SPI devices. In a future refactor the slave select logic will need to be made more flexible to support shields which use the standard CS0/CS1 pins

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.RefactorRegisterManager
{
	using System;
	using System.Diagnostics;
	using System.Runtime.InteropServices.WindowsRuntime;
	using Windows.Devices.Gpio;
	using Windows.Devices.Spi;

	public sealed class RegisterManager
	{
		private GpioPin ChipSelectGpioPin = null;
		private SpiDevice Device = null;
		private const byte RegisterAddressReadMask = 0X7f;
		private const byte RegisterAddressWriteMask = 0x80;

		public RegisterManager(int chipSelectPin)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(0)
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,
			};

			// Chip select pin configuration
			GpioController gpioController = GpioController.GetDefault();
			ChipSelectGpioPin = gpioController.OpenPin(chipSelectPin);
			ChipSelectGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			Device = spiController.GetDevice(settings);
		}

		public Byte ReadByte(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[1];
			Debug.Assert(Device != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			Device.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer[0];
		}

		public ushort ReadWord(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[2];
			Debug.Assert(Device != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			Device.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return (ushort)(readBuffer[1] + (readBuffer[0] << 8));
		}

		public byte[] Read(byte address, int length)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[length];
			Debug.Assert(Device != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			Device.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer;
		}

		public void WriteByte(byte address, byte value)
		{
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, value };
			Debug.Assert(Device != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void WriteWord(byte address, ushort value)
		{
			byte[] valueBytes = BitConverter.GetBytes(value);
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, valueBytes[0], valueBytes[1] };
			Debug.Assert(Device != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void Write(byte address, [ReadOnlyArray()] byte[] bytes)
		{
			byte[] writeBuffer = new byte[1 + bytes.Length];
			Debug.Assert(Device != null);

			Array.Copy(bytes, 0, writeBuffer, 1, bytes.Length);
			writeBuffer[0] = address |= RegisterAddressWriteMask;

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Device.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void Dump(byte start, byte finish)
		{
			Debug.Assert(Device != null);

			Debug.WriteLine("Register dump");

			for (byte registerIndex = start; registerIndex <= finish; registerIndex++)
			{
				byte registerValue = this.ReadByte(registerIndex);

				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", registerIndex, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));
			}
		}
	}
}

I think the next steps will be introducing an enumeration for the SX127X registers, moving the initialisation code into the Rfm9XDevice class, along with the interrupt handler.

After looking at other Windows 10 IoT Core and Arduino RFM9X libraries I think I'll try and keep the number of getter/setters to a minimum and focus on configuring the device at startup. The initialise method may end up having a lot of parameters but I should be able to hide ones a user doesn't need for their application with named and optional parameters.

RFM95/96/97/98 shield library Part8

Transmit and Receive with Interrupts

For the final iteration of the “nasty” test harness I got the interrupts working for the transmitting and receiving of messages. It’s not quite simultaneous, the code sends a message every 10 seconds then goes back to receive continuous mode after each message has been sent.

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ReceiveTransmitInterrupt
{
	using System;
	using System.Diagnostics;
	using System.Text;
	using System.Runtime.InteropServices.WindowsRuntime;
	using System.Threading.Tasks;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Spi;
	using Windows.Devices.Gpio;

	public sealed class Rfm9XDevice
	{
		private SpiDevice Rfm9XLoraModem = null;
		private GpioPin ChipSelectGpioPin = null;
		private GpioPin InterruptGpioPin = null;
		private const byte RegisterAddressReadMask = 0X7f;
		private const byte RegisterAddressWriteMask = 0x80;

		public Rfm9XDevice(byte chipSelectPin, byte resetPin, byte interruptPin)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(0)
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,
			};

			// Chip select pin configuration
			GpioController gpioController = GpioController.GetDefault();
			ChipSelectGpioPin = gpioController.OpenPin(chipSelectPin);
			ChipSelectGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			// Reset pin configuration to do factory reset
			GpioPin resetGpioPin = gpioController.OpenPin(resetPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			resetGpioPin.Write(GpioPinValue.Low);
			Task.Delay(10);
			resetGpioPin.Write(GpioPinValue.High);
			Task.Delay(10);

			// Interrupt pin for RX message & TX done notification
			InterruptGpioPin = gpioController.OpenPin(interruptPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Input);

			InterruptGpioPin.ValueChanged += InterruptGpioPin_ValueChanged;

			Rfm9XLoraModem = spiController.GetDevice(settings);
		}

		private void InterruptGpioPin_ValueChanged(GpioPin sender, GpioPinValueChangedEventArgs args)
		{
			if (args.Edge != GpioPinEdge.RisingEdge)
			{
				return;
			}

			byte IrqFlags = this.RegisterReadByte(0x12); // RegIrqFlags
			Debug.WriteLine(string.Format("RegIrqFlags {0}", Convert.ToString(IrqFlags, 2).PadLeft(8, '0')));
			if ((IrqFlags & 0b01000000) == 0b01000000)  // RxDone
			{
				Debug.WriteLine("Receive-Message");
				byte currentFifoAddress = this.RegisterReadByte(0x10); // RegFifiRxCurrent
				this.RegisterWriteByte(0x0d, currentFifoAddress); // RegFifoAddrPtr

				byte numberOfBytes = this.RegisterReadByte(0x13); // RegRxNbBytes

				// Allocate buffer for message
				byte[] messageBytes = new byte[numberOfBytes];

				for (int i = 0; i < numberOfBytes; i++)
				{
					messageBytes[i] = this.RegisterReadByte(0x00); // RegFifo
				}

				string messageText = UTF8Encoding.UTF8.GetString(messageBytes);
				Debug.WriteLine("Received {0} byte message {1}", messageBytes.Length, messageText);
			}

			if ((IrqFlags & 0b00001000) == 0b00001000)  // TxDone
			{
				this.RegisterWriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous
				Debug.WriteLine("Transmit-Done");
			}

			this.RegisterWriteByte(0x40, 0b00000000); // RegDioMapping1 0b00000000 DI0 RxReady & TxReady
			this.RegisterWriteByte(0x12, 0xff);// RegIrqFlags
		}

		public Byte RegisterReadByte(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[1];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer[0];
		}

		public ushort RegisterReadWord(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[2];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return (ushort)(readBuffer[1] + (readBuffer[0] << 8));
		}

		public byte[] RegisterRead(byte address, int length)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[length];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer;
		}

		public void RegisterWriteByte(byte address, byte value)
		{
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, value };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWriteWord(byte address, ushort value)
		{
			byte[] valueBytes = BitConverter.GetBytes(value);
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, valueBytes[0], valueBytes[1] };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWrite(byte address, [ReadOnlyArray()] byte[] bytes)
		{
			byte[] writeBuffer = new byte[1 + bytes.Length];
			Debug.Assert(Rfm9XLoraModem != null);

			Array.Copy(bytes, 0, writeBuffer, 1, bytes.Length);
			writeBuffer[0] = address |= RegisterAddressWriteMask;

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterDump()
		{
			Debug.WriteLine("Register dump");
			for (byte registerIndex = 0; registerIndex <= 0x42; registerIndex++)
			{
				byte registerValue = this.RegisterReadByte(registerIndex);

				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", registerIndex, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));
			}
		}
	}


	public sealed class StartupTask : IBackgroundTask
	{
		private const byte ChipSelectLine = 25;
		private const byte ResetLine = 17;
		private const byte InterruptLine = 4;
		private Rfm9XDevice rfm9XDevice = new Rfm9XDevice(ChipSelectLine, ResetLine, InterruptLine);
		private byte NessageCount = Byte.MaxValue;

		public void Run(IBackgroundTaskInstance taskInstance)
		{
			// Put device into LoRa + Sleep mode
			rfm9XDevice.RegisterWriteByte(0x01, 0b10000000); // RegOpMode

			// Set the frequency to 915MHz
			byte[] frequencyWriteBytes = { 0xE4, 0xC0, 0x00 }; // RegFrMsb, RegFrMid, RegFrLsb
			rfm9XDevice.RegisterWrite(0x06, frequencyWriteBytes);

			rfm9XDevice.RegisterWriteByte(0x0F, 0x0); // RegFifoRxBaseAddress

			// More power PA Boost
			rfm9XDevice.RegisterWriteByte(0x09, 0b10000000); // RegPaConfig

			rfm9XDevice.RegisterWriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous


			while (true)
			{
				rfm9XDevice.RegisterWriteByte(0x0E, 0x0); // RegFifoTxBaseAddress

				// Set the Register Fifo address pointer
				rfm9XDevice.RegisterWriteByte(0x0D, 0x0); // RegFifoAddrPtr

				string messageText = "W10 IoT Core LoRa! " + NessageCount.ToString();
				NessageCount -= 1;

				// load the message into the fifo
				byte[] messageBytes = UTF8Encoding.UTF8.GetBytes(messageText);
				foreach (byte b in messageBytes)
				{
					rfm9XDevice.RegisterWriteByte(0x0, b); // RegFifo
				}

				// Set the length of the message in the fifo
				rfm9XDevice.RegisterWriteByte(0x22, (byte)messageBytes.Length); // RegPayloadLength
				rfm9XDevice.RegisterWriteByte(0x40, 0b01000000); // RegDioMapping1 0b00000000 DI0 RxReady & TxReady
				rfm9XDevice.RegisterWriteByte(0x01, 0b10000011); // RegOpMode


				Debug.WriteLine("Sending {0} bytes message {1}", messageBytes.Length, messageText);

				Task.Delay(10000).Wait();
			}
		}
	}
}

The diagnostic output shows inbound and outbound messages

RegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 80
Sending 22 bytes message W10 IoT Core LoRa! 255
RegIrqFlags 01011000
Receive-Message
Received 16 byte message HeLoRa World! 80
Transmit-Done
RegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 82
RegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 84
The thread 0xf20 has exited with code 0 (0x0).
The thread 0xbe4 has exited with code 0 (0x0).
RegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 86
RegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 88
Sending 22 bytes message W10 IoT Core LoRa! 254
RegIrqFlags 00001000
Transmit-Done
RegIrqFlags 01110000
Receive-Message
Received 46 byte message ��Lh��ORegIrqFlags 01010000
Receive-Message
Received 16 byte message HeLoRa World! 92
The RegIrqFlags 01011000 indicates the RxDone, ValidHeader, and TxDone flags were set which was what I was expecting. Note the interference, the 46 byte packet

Next step is some refactoring to extract the register access code and figuring out a reasonable approach for RMF9X library.

RFM95/96/97/98 shield library Part7

Transmit Interrupt

Starting with the TransmitBasic sample application I modified the code so that a hardware interrupt (specified in RegDioMapping1) was generated on TxDone (FIFO Payload Transmission completed).

My first couple of attempts didn’t work as I had the RegDioMapping1 wrong and the RegIrqFlags bitmasks in the interrupt handler weren’t consistent (need to get rid of the magic numbers & bitmasks soon)

The application inserts a message into the RFM95 transmit FIFO every 10 seconds with confirmation of transmission displayed shortly afterwards

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.TransmitInterrupt
{
	using System;
	using System.Diagnostics;
	using System.Text;
	using System.Runtime.InteropServices.WindowsRuntime;
	using System.Threading.Tasks;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Spi;
	using Windows.Devices.Gpio;

	public sealed class Rfm9XDevice
	{
		private SpiDevice Rfm9XLoraModem = null;
		private GpioPin ChipSelectGpioPin = null;
		private GpioPin InterruptGpioPin = null;
		private const byte RegisterAddressReadMask = 0X7f;
		private const byte RegisterAddressWriteMask = 0x80;

		public Rfm9XDevice(byte chipSelectPin, byte resetPin, byte interruptPin)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(0)
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,
			};

			// Chip select pin configuration
			GpioController gpioController = GpioController.GetDefault();
			ChipSelectGpioPin = gpioController.OpenPin(chipSelectPin);
			ChipSelectGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			// Reset pin configuration to do factory reset
			GpioPin resetGpioPin = gpioController.OpenPin(resetPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			resetGpioPin.Write(GpioPinValue.Low);
			Task.Delay(10);
			resetGpioPin.Write(GpioPinValue.High);
			Task.Delay(10);

			// Interrupt pin for RX message & TX done notification
			InterruptGpioPin = gpioController.OpenPin(interruptPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Input);

			InterruptGpioPin.ValueChanged += InterruptGpioPin_ValueChanged;

			Rfm9XLoraModem = spiController.GetDevice(settings);
		}

		private void InterruptGpioPin_ValueChanged(GpioPin sender, GpioPinValueChangedEventArgs args)
		{
			if (args.Edge != GpioPinEdge.RisingEdge)
			{
				return;
			}

			byte IrqFlags = this.RegisterReadByte(0x12); // RegIrqFlags
			Debug.WriteLine(string.Format("RegIrqFlags {0}", Convert.ToString(IrqFlags, 2).PadLeft(8, '0')));

			if ((IrqFlags & 0b00001000) == 0b00001000)  // TxDone
			{
				Debug.WriteLine("Transmit-Done");
			}

			this.RegisterWriteByte(0x12, 0xff);// RegIrqFlags
		}

		public Byte RegisterReadByte(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[1];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer[0];
		}

		public ushort RegisterReadWord(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[2];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return (ushort)(readBuffer[1] + (readBuffer[0] << 8));
		}

		public byte[] RegisterRead(byte address, int length)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[length];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer;
		}

		public void RegisterWriteByte(byte address, byte value)
		{
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, value };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWriteWord(byte address, ushort value)
		{
			byte[] valueBytes = BitConverter.GetBytes(value);
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, valueBytes[0], valueBytes[1] };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWrite(byte address, [ReadOnlyArray()] byte[] bytes)
		{
			byte[] writeBuffer = new byte[1 + bytes.Length];
			Debug.Assert(Rfm9XLoraModem != null);

			Array.Copy(bytes, 0, writeBuffer, 1, bytes.Length);
			writeBuffer[0] = address |= RegisterAddressWriteMask;

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterDump()
		{
			Debug.WriteLine("Register dump");
			for (byte registerIndex = 0; registerIndex <= 0x42; registerIndex++)
			{
				byte registerValue = this.RegisterReadByte(registerIndex);

				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", registerIndex, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));
			}
		}
	}

	public sealed class StartupTask : IBackgroundTask
	{
		private const byte ChipSelectLine = 25;
		private const byte ResetLine = 17;
		private const byte InterruptLine = 4;
		private Rfm9XDevice rfm9XDevice = new Rfm9XDevice(ChipSelectLine, ResetLine, InterruptLine);

		public void Run(IBackgroundTaskInstance taskInstance)
		{
			// Put device into LoRa + Sleep mode
			rfm9XDevice.RegisterWriteByte(0x01, 0b10000000); // RegOpMode

			// Set the frequency to 915MHz
			byte[] frequencyWriteBytes = { 0xE4, 0xC0, 0x00 }; // RegFrMsb, RegFrMid, RegFrLsb
			rfm9XDevice.RegisterWrite(0x06, frequencyWriteBytes);

			// More power PA Boost
			rfm9XDevice.RegisterWriteByte(0x09, 0b10000000); // RegPaConfig

			// Interrupt on TxDone
			rfm9XDevice.RegisterWriteByte(0x40, 0b01000000); // RegDioMapping1 0b00000000 DI0 TxDone

			while (true)
			{
				// Set the Register Fifo address pointer
				rfm9XDevice.RegisterWriteByte(0x0E, 0x80); // RegFifoTxBaseAddress

				// Set the Register Fifo address pointer
				rfm9XDevice.RegisterWriteByte(0x0D, 0x0); // RegFifoAddrPtr

				string messageText = "Hello LoRa!";

				// load the message into the fifo
				byte[] messageBytes = UTF8Encoding.UTF8.GetBytes(messageText);
				foreach (byte b in messageBytes)
				{
					rfm9XDevice.RegisterWriteByte(0x0, b); // RegFifo
				}

				// Set the length of the message in the fifo
				rfm9XDevice.RegisterWriteByte(0x22, (byte)messageBytes.Length); // RegPayloadLength
				Debug.WriteLine("Sending {0} bytes message {1}", messageBytes.Length, messageText);
				rfm9XDevice.RegisterWriteByte(0x01, 0b10000011); // RegOpMode

				Task.Delay(10000).Wait();
			}
		}
	}
}

The output in the debug window

Sending 11 bytes message Hello LoRa!
'backgroundTaskHost.exe' (CoreCLR: CoreCLR_UWP_Domain): Loaded 'C:\Data\Users\DefaultAccount\AppData\Local\DevelopmentFiles\TransmitInterrupt-uwpVS.Debug_ARM.Bryn.Lewis\System.Runtime.Extensions.dll'. Skipped loading symbols. Module is optimized and the debugger option 'Just My Code' is enabled.
RegIrqFlags 00001000
Transmit-Done
The thread 0xe38 has exited with code 0 (0x0).
Sending 11 bytes message Hello LoRa!
RegIrqFlags 00001000
Transmit-Done
The thread 0x92c has exited with code 0 (0x0).
Sending 11 bytes message Hello LoRa!
RegIrqFlags 00001000
Transmit-Done
The thread 0xcc4 has exited with code 0 (0x0).
Sending 11 bytes message Hello LoRa!
RegIrqFlags 00001000
Transmit-Done
The thread 0xb54 has exited with code 0 (0x0).

On the Arduino test client the serial monitor displayed

ending HeLoRa World! 0
Sending HeLoRa World! 2
Sending HeLoRa World! 4
Sending HeLoRa World! 6
Sending HeLoRa World! 8
Sending HeLoRa World! 10
Message: Hello LoRa!
RSSI: -67
Snr: 9.00

Sending HeLoRa World! 12
Sending HeLoRa World! 14
Sending HeLoRa World! 16
Sending HeLoRa World! 18
Message: Hello LoRa!
RSSI: -67
Snr: 9.50

Sending HeLoRa World! 20
Sending HeLoRa World! 22

The next step is most probably either chopping apart the existing code, modularising it,  and removing the magic numbers etc. or getting bidirectional interrupt driven connectivity working.

RFM95/96/97/98 shield library Part6

Receive Interrupt

The HopeRF datasheet coverage of how the hardware interrupts should be configured (RegDioMapping1 & RegDioMapping2) was a bit confusing and some of the other values where wrong e.g. RegVersion returned 0x12 rather than 0x11.

I figured that getting interrupts working was a good choice to do next while the code was still relatively small. From the LMIC LoRaWAN stack implementations I have looked at the mapping of digital pins in hardware and software appeared critical.

I modified my test application and set what I though was the correct RegDioMapping1 for DIO0 but the application didn’t work the way I expected. After some searching then tinkering I went back and checked my approach against the Semtech SX1276 datasheet. I found the byte ordering was backwards to what I assumed (The two DIO0 bits were bits 7&6 of RegDioMapping1 not bits 1&0)

I also added an extra parameter to the constructor to pass in the interrupt pin number, replaced the message sending code, with an infinite sleep, then wired up the interrupt handler. In this proof of concept the interrupt handler just displays the received message which is a bit fugly.

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ReceiveInterrupt
{
	using System;
	using System.Diagnostics;
	using System.Text;
	using System.Runtime.InteropServices.WindowsRuntime;
	using System.Threading.Tasks;
	using Windows.ApplicationModel.Background;
	using Windows.Devices.Spi;
	using Windows.Devices.Gpio;

	public sealed class Rfm9XDevice
	{
		private SpiDevice Rfm9XLoraModem = null;
		private GpioPin ChipSelectGpioPin = null;
		private GpioPin InterruptGpioPin = null;
		private const byte RegisterAddressReadMask = 0X7f;
		private const byte RegisterAddressWriteMask = 0x80;

		public Rfm9XDevice(byte chipSelectPin, byte resetPin, byte interruptPin)
		{
			SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
			var settings = new SpiConnectionSettings(0)
			{
				ClockFrequency = 500000,
				Mode = SpiMode.Mode0,
			};

			// Chip select pin configuration
			GpioController gpioController = GpioController.GetDefault();
			ChipSelectGpioPin = gpioController.OpenPin(chipSelectPin);
			ChipSelectGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			// Reset pin configuration to do factory reset
			GpioPin resetGpioPin = gpioController.OpenPin(resetPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Output);
			resetGpioPin.Write(GpioPinValue.Low);
			Task.Delay(10);
			resetGpioPin.Write(GpioPinValue.High);
			Task.Delay(10);

			// Interrupt pin for RX message & TX done notification
			InterruptGpioPin = gpioController.OpenPin(interruptPin);
			resetGpioPin.SetDriveMode(GpioPinDriveMode.Input);

			InterruptGpioPin.ValueChanged += InterruptGpioPin_ValueChanged;

			Rfm9XLoraModem = spiController.GetDevice(settings);
		}

		private void InterruptGpioPin_ValueChanged(GpioPin sender, GpioPinValueChangedEventArgs args)
		{
			if (args.Edge != GpioPinEdge.RisingEdge)
			{
				return;
			}

			byte IrqFlags = this.RegisterReadByte(0x12); // RegIrqFlags
			Debug.WriteLine( string.Format("RegIrqFlags {0}", Convert.ToString(IrqFlags, 2).PadLeft(8, '0')));
			if ((IrqFlags & 0b01000000) == 0b01000000)  // RxDone
			{
				Debug.WriteLine("Receive-Message");
				byte currentFifoAddress = this.RegisterReadByte(0x10); // RegFifiRxCurrent
				this.RegisterWriteByte(0x0d, currentFifoAddress); // RegFifoAddrPtr

				byte numberOfBytes = this.RegisterReadByte(0x13); // RegRxNbBytes

				// Allocate buffer for message
				byte[] messageBytes = new byte[numberOfBytes];

				for (int i = 0; i < numberOfBytes; i++)
				{
					messageBytes[i] = this.RegisterReadByte(0x00); // RegFifo
				}

				string messageText = UTF8Encoding.UTF8.GetString(messageBytes);
				Debug.WriteLine("Received {0} byte message {1}", messageBytes.Length, messageText);
			}

			this.RegisterWriteByte(0x12, 0xff);// RegIrqFlags
		}

		public Byte RegisterReadByte(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[1];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer[0];
		}

		public ushort RegisterReadWord(byte address)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[2];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return (ushort)(readBuffer[1] + (readBuffer[0] << 8));
		}

		public byte[] RegisterRead(byte address, int length)
		{
			byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
			byte[] readBuffer = new byte[length];
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			Rfm9XLoraModem.Read(readBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);

			return readBuffer;
		}

		public void RegisterWriteByte(byte address, byte value)
		{
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, value };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWriteWord(byte address, ushort value)
		{
			byte[] valueBytes = BitConverter.GetBytes(value);
			byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, valueBytes[0], valueBytes[1] };
			Debug.Assert(Rfm9XLoraModem != null);

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterWrite(byte address, [ReadOnlyArray()] byte[] bytes)
		{
			byte[] writeBuffer = new byte[1 + bytes.Length];
			Debug.Assert(Rfm9XLoraModem != null);

			Array.Copy(bytes, 0, writeBuffer, 1, bytes.Length);
			writeBuffer[0] = address |= RegisterAddressWriteMask;

			ChipSelectGpioPin.Write(GpioPinValue.Low);
			Rfm9XLoraModem.Write(writeBuffer);
			ChipSelectGpioPin.Write(GpioPinValue.High);
		}

		public void RegisterDump()
		{
			Debug.WriteLine("Register dump");
			for (byte registerIndex = 0; registerIndex <= 0x42; registerIndex++)
			{
				byte registerValue = this.RegisterReadByte(registerIndex);

				Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", registerIndex, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));
			}
		}
	}

	public sealed class StartupTask : IBackgroundTask
	{
		private const byte ChipSelectLine = 25;
		private const byte ResetLine = 17;
		private const byte InterruptLine = 4;
		private Rfm9XDevice rfm9XDevice = new Rfm9XDevice(ChipSelectLine, ResetLine, InterruptLine);

		public void Run(IBackgroundTaskInstance taskInstance)
		{
			// Put device into LoRa + Sleep mode
			rfm9XDevice.RegisterWriteByte(0x01, 0b10000000); // RegOpMode

			// Set the frequency to 915MHz
			byte[] frequencyWriteBytes = { 0xE4, 0xC0, 0x00 }; // RegFrMsb, RegFrMid, RegFrLsb
			rfm9XDevice.RegisterWrite(0x06, frequencyWriteBytes);

			rfm9XDevice.RegisterWriteByte(0x0F, 0x0); // RegFifoRxBaseAddress

			rfm9XDevice.RegisterWriteByte(0x40, 0b00000000); // RegDioMapping1 0b00000000 DIO0 RxReady & TxReady

			rfm9XDevice.RegisterWriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous

			rfm9XDevice.RegisterDump();

			Debug.WriteLine("Receive-Wait");
			Task.Delay(-1).Wait();
		}
	}
}

The output in the output debug window looked like this

RegIrqFlags 01010000
Receive-Message
Received 15 byte message HeLoRa World! 0
RegIrqFlags 01010000
Receive-Message
Received 15 byte message HeLoRa World! 2
RegIrqFlags 01010000
Receive-Message
Received 15 byte message HeLoRa World! 4
RegIrqFlags 01010000
Receive-Message
Received 15 byte message HeLoRa World! 6

Next step will be wiring up the transmit done interrupt.



RFM95/96/97/98 shield library Part5



Receive Basic

The receive code worked reliably after a couple of attempts. Initially, I was setting the RxTimeout bit on the RegIrqFlags register after retrieving the message, rather than the RxDone bit, and then found I was setting the receive single rather than receive continuous bit of RegOpMode.

I did some basic stress testing with a number of Arduino devices running a slightly modified version of the LoRaSetSyncWord example and my C# code didn’t appear to be dropping messages.

//---------------------------------------------------------------------------------
// Copyright (c) August 2018, devMobile Software
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
//
//---------------------------------------------------------------------------------
namespace devMobile.IoT.Rfm9x.ReceiveBasic
{
   using System;
   using System.Diagnostics;
   using System.Text;
   using System.Runtime.InteropServices.WindowsRuntime;
   using System.Threading.Tasks;
   using Windows.ApplicationModel.Background;
   using Windows.Devices.Spi;
   using Windows.Devices.Gpio;

   public sealed class Rfm9XDevice
   {
      private SpiDevice Rfm9XLoraModem = null;
      private GpioPin ChipSelectGpioPin = null;
      private const byte RegisterAddressReadMask = 0X7f;
      private const byte RegisterAddressWriteMask = 0x80;

      public Rfm9XDevice(byte chipSelectPin, byte resetPin)
      {
         SpiController spiController = SpiController.GetDefaultAsync().AsTask().GetAwaiter().GetResult();
         var settings = new SpiConnectionSettings(0)
         {
            ClockFrequency = 500000,
            Mode = SpiMode.Mode0,
         };

         // Chip select pin configuration
         GpioController gpioController = GpioController.GetDefault();
         ChipSelectGpioPin = gpioController.OpenPin(chipSelectPin);
         ChipSelectGpioPin.SetDriveMode(GpioPinDriveMode.Output);
         ChipSelectGpioPin.Write(GpioPinValue.High);

         // Reset pin configuration to do factory reset
         GpioPin resetGpioPin = gpioController.OpenPin(resetPin);
         resetGpioPin.SetDriveMode(GpioPinDriveMode.Output);
         resetGpioPin.Write(GpioPinValue.Low);
         Task.Delay(10);
         resetGpioPin.Write(GpioPinValue.High);
         Task.Delay(10);

         Rfm9XLoraModem = spiController.GetDevice(settings);
         }

	public Byte RegisterReadByte(byte address)
	{
		byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
		byte[] readBuffer = new byte[1];
		Debug.Assert(Rfm9XLoraModem != null);

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		Rfm9XLoraModem.Read(readBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);

		return readBuffer[0];
	}

	public ushort RegisterReadWord(byte address)
	{
		byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
		byte[] readBuffer = new byte[2];
		Debug.Assert(Rfm9XLoraModem != null);

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		Rfm9XLoraModem.Read(readBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);

		return (ushort)(readBuffer[1] + (readBuffer[0] << 8));
	}

	public byte[] RegisterRead(byte address, int length)
	{
		byte[] writeBuffer = new byte[] { address &= RegisterAddressReadMask };
		byte[] readBuffer = new byte[length];
		Debug.Assert(Rfm9XLoraModem != null);

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		Rfm9XLoraModem.Read(readBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);

		return readBuffer;
	}

	public void RegisterWriteByte(byte address, byte value)
	{
		byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, value };
		Debug.Assert(Rfm9XLoraModem != null);

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);
	}

	public void RegisterWriteWord(byte address, ushort value)
	{
		byte[] valueBytes = BitConverter.GetBytes(value);
		byte[] writeBuffer = new byte[] { address |= RegisterAddressWriteMask, valueBytes[0], valueBytes[1] };
		Debug.Assert(Rfm9XLoraModem != null);

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);
	}

	public void RegisterWrite(byte address, [ReadOnlyArray()] byte[] bytes)
	{
		byte[] writeBuffer = new byte[1 + bytes.Length];
		Debug.Assert(Rfm9XLoraModem != null);

		Array.Copy(bytes, 0, writeBuffer, 1, bytes.Length);
		writeBuffer[0] = address |= RegisterAddressWriteMask;

		ChipSelectGpioPin.Write(GpioPinValue.Low);
		Rfm9XLoraModem.Write(writeBuffer);
		ChipSelectGpioPin.Write(GpioPinValue.High);
	}

	public void RegisterDump()
	{
		Debug.WriteLine("Register dump");
		for (byte registerIndex = 0; registerIndex <= 0x42; registerIndex++)
		{
			byte registerValue = this.RegisterReadByte(registerIndex);

			Debug.WriteLine("Register 0x{0:x2} - Value 0X{1:x2} - Bits {2}", registerIndex, registerValue, Convert.ToString(registerValue, 2).PadLeft(8, '0'));
		}
	}
}

public sealed class StartupTask : IBackgroundTask
{
	private const int ChipSelectLine = 25;
	private const int ResetLine = 17;
	private Rfm9XDevice rfm9XDevice = new Rfm9XDevice(ChipSelectLine, ResetLine);

	public void Run(IBackgroundTaskInstance taskInstance)
	{
		// Put device into LoRa + Sleep mode
		rfm9XDevice.RegisterWriteByte(0x01, 0b10000000); // RegOpMode

		// Set the frequency to 915MHz
		byte[] frequencyWriteBytes = { 0xE4, 0xC0, 0x00 }; // RegFrMsb, RegFrMid, RegFrLsb
		rfm9XDevice.RegisterWrite(0x06, frequencyWriteBytes);

		rfm9XDevice.RegisterWriteByte(0x0F, 0x0); // RegFifoRxBaseAddress

		rfm9XDevice.RegisterWriteByte(0x01, 0b10000101); // RegOpMode set LoRa & RxContinuous

		while (true)
		{
			// Wait until a packet is received, no timeouts in PoC
			Debug.WriteLine("Receive-Wait");
			byte IrqFlags = rfm9XDevice.RegisterReadByte(0x12); // RegIrqFlags
			while ((IrqFlags & 0b01000000) == 0)  // wait until RxDone cleared
			{
				Task.Delay(20).Wait();
				IrqFlags = rfm9XDevice.RegisterReadByte(0x12); // RegIrqFlags
				Debug.Write(".");
			}
			Debug.WriteLine("");

			Debug.WriteLine("Receive-Message");
			byte currentFifoAddress = rfm9XDevice.RegisterReadByte(0x10); // RegFifiRxCurrent
			rfm9XDevice.RegisterWriteByte( 0x0d, currentFifoAddress); // RegFifoAddrPtr

			byte numberOfBytes = rfm9XDevice.RegisterReadByte(0x13); // RegRxNbBytes

			// Allocate buffer for message
			byte[] messageBytes = new byte[numberOfBytes];

			for (int i = 0; I < numberOfBytes; i++)
			{
				messageBytes[i] = rfm9XDevice.RegisterReadByte(0x00); // RegFifo
			}
            string messageText = UTF8Encoding.UTF8.GetString(messageBytes);
            Debug.WriteLine("Received {0} byte message {1}", messageBytes.Length, messageText);

            rfm9XDevice.RegisterWriteByte(0x12, 0b01000000); // RegIrqFlags clear RxDone bit

            Debug.WriteLine("Receive-Done");
         }
      }
   }
}

With 3 client devices transmitting the debug output looked like this

Receive-Wait

Receive-Message
Received 16 byte message HeLoRa World! 14
Receive-Done
Receive-Wait
……………………………………………………
Receive-Message
Received 16 byte message HeLoRa World! 16
Receive-Done
Receive-Wait
………………………………………………………………………………….
Receive-Message
Received 16 byte message HeLoRa World! 18
Receive-Done
Receive-Wait
………………………………………………………………………….
Receive-Message
Received 16 byte message HeLoRa World! 20
Receive-Done
Receive-Wait
………………
Receive-Message
Received 16 byte message HelloRa World! 0
Receive-Done
Receive-Wait
………………………
Receive-Message
Received 16 byte message HeLoRa World! 22
Receive-Done
Receive-Wait

Most LoRa libraries include the Received Signal Strength Indication(RSSI) & Signal To noise ratio (SNR) information with the received packet. The RSSI needs to be “adjusted” by a constant depending on the frequency so that can wait until after configuration approach has been decided.

Transmitting/receiving with interrupts or design goals next.
